Geocell erosion control grid H100
Geocell erosion control grid H100
- Expanded panel size: 6m x 2.55m (15.3 sqm)
- Cell depth: 100mm
- Car park pathways, erosion control and retaining wall
- More information below
- Specifications and Downloads
- Product Description
- Installation videos
Specifications and Downloads
Specifications and Downloads
- Used for vehicle applications, pedestrian areas, erosion control, tree root protection and landscaping
- Expanded panel size: 6m x 2.55m (15.3 sqm)
- Cell depth: 100mm
- Weight: 13kg
- Material: modified polyethylene
- Slope gradient up to 1:1.5 (33 degrees)
- Recommended to use 2-3 ground rebar stakes per sqm
- Recommended fill for vehicular applications: gravel (20mm or larger)
- Recommended fill for erosion control: grass/soil
Product Description
Product Description
Vodaland's Ultimate Geocell Erosion Control Grid - Geocell H100
Geocell erosion control grid H100 is a 3D cellular confinement system that has a multitude of applications. First, it is an erosion control system that can be used on slopes (up to 33 degrees) and its 100% permeable cellular structure design ensures that soil is confined allowing water to pass down the slope without eroding soil. Geocell H100 can also be used for tree root protection and retaining walls.
Each section of the geoweb grid extends over 15.3 sq. meters or 164.5 sq. ft. providing ample coverage for various projects. Fitting these section is simple - simply stretch them over your desired area and anchor them down securely. Fancy a custom layout? No problem! Sections can be cut and seamlessly connected to each other, ensuring a tailored fit for your unique needs.
